Ceramic Aligning Ball Bearings

Precision：ABEC-1,ABEC-3,ABEC-5,ABEC-7
Material：Si3N4,ZrO2
OEM service：Custom Bearing size,logo,packing
Certifications：ISO9001 or IATF 16949
Payment terms：T/T, L/C, D/A,D/P,Western Union
Capacity：200,000pcs
Delivery time：1 week for sample, 30-60days for mass production
Packing details：single plasitc bag+ single box+carton

Bearings from Wuxi F&T Machinery Co.,Ltd

Product specifications

Dimensions(mm)			Chamfer	Bearing NO.	Weight（kg)
Dimensions(mm)			Chamfer		Weight（kg)
d	D	B	r(min)		ZrO2	Si3N4
d	D	B	r(min)		ZrO2	Si3N4
5	19	6	0.3	135	0.007	0.004
6	19	6	0.3	126	0.007	0.004
7	22	7	0.3	127	0.011	0.006
8	22	7	0.3	108	0.011	0.006
9	26	8	0.6	129	0.017	0.009
10	30	9	0.6	1200	0.026	0.014
10	30	14	0.6	2200	0.036	0.019
10	25	11	0.6	1300	0.045	0.024
10	25	17	0.6	2300	0.065	0.035
12	32	10	0.6	1201	0.031	0.016
12	32	14	0.6	2201	0.041	0.022
12	37	12	1	1301	0.052	0.027
12	37	17	1	2301	0.073	0.039
15	35	11	0.6	1202	0.038	0.02
15	35	14	0.6	2202	0.046	0.025
15	42	13	1	1302	0.072	0.039
15	42	17	1	2302	0.088	0.047
17	40	12	0.6	1203	0.056	0.03
17	40	16	0.6	2203	0.068	0.036
17	47	14	1	1303	0.1	0.053
17	47	19	1	2303	0.12	0.065
20	47	14	1	1204	0.09	0.049
20	47	18	1	2204	0.11	0.057
20	52	15	1.1	1304	0.13	0.067
20	52	21	1.1	2304	0.16	0.086
25	52	15	1	1205	0.11	0.058
25	52	18	1	2205	0.13	0.067
25	62	17	1.1	1305	0.2	0.11
25	62	24	1.1	2305	0.26	0.14
30	62	16	1	1206	0.17	0.09
30	62	20	1	2206	0.2	0.11
30	72	19	1.1	1306	0.3	0.16
30	72	27	1.1	2306	0.38	0.21
35	72	17	1.1	1207	0.25	0.13
35	72	23	1.1	2207	0.31	0.17
35	80	21	1.5	1307	0.39	0.21
35	80	31	1.5	2307	0.52	0.28
40	80	18	1.1	1208	0.32	0.17
40	80	23	1.1	2208	0.39	0.21
40	90	23	1.5	1308	0.55	0.29
40	90	33	1.5	2308	0.71	0.38
45	85	19	1.1	1209	0.36	0.19
45	85	23	1.1	2209	0.42	0.22
45	100	25	1.5	1309	0.74	0.39
45	100	36	1.5	2309	0.95	0.5
50	90	20	1.1	1210	0.4	0.22
50	90	23	1.1	2210	0.45	0.24
50	110	27	2	1310	0.93	0.5
50	110	40	2	2310	1.26	0.67
55	100	21	1.5	1211	0.54	0.29
55	100	25	1.5	2211	0.62	0.33
55	120	29	2	1311	1.22	0.65
55	120	43	2	2311	1.62	0.86
60	110	22	1.5	1212	0.69	0.37
60	110	28	1.5	2212	0.84	0.45
60	130	31	2.1	1312	1.51	0.8
60	130	46	2.1	2312	2	1.07
65	120	23	1.5	1213	0.88	0.47
65	120	31	1.5	2213	1.12	0.6
65	140	33	2.1	1313	1.88	1.01
65	140	48	2.1	2313	2.48	1.33
70	125	24	1.5	1214	0.97	0.52
70	125	31	1.5	2214	1.17	0.62
70	150	35	2.1	1314	2.3	1.23
70	150	51	2.1	2314	3.25	1.74
75	130	25	1.5	1215	1.05	0.56
75	130	31	1.5	2215	1.25	0.66
80	140	26	2	1216	1.28	0.69
80	140	33	2	2216	1.55	0.82
85	150	28	2	1217	1.59	0.85
85	150	36	2	2217	1.94	1.03
85	180	41	3	1317	3.78	2.01
85	180	60	3	2317	5.3	2.83
90	160	30	2	1218	1.91	1.02
90	160	40	2	2218	2.56	1.37
90	190	43	3	1318	4.4	2.34
90	190	64	3	2318	6.35	3.38
95	170	32	3.1	1219	2.35	1.25
95	170	43	2.1	2219	3.08	1.64
95	200	45	3	1319	5.07	2.7
95	200	67	3	2319	7.36	3.93
100	180	34	2.1	1220	2.8	1.5
100	180	46	2.1	2220	3.75	2
105	190	36	2.1	1221	3.36	1.8
105	190	50	2.1	2221	4.67	2.49
110	200	38	2.1	1222	3.96	2.11
110	200	53	2.1	2222	5.46	2.91

https://www.fertbearing.com/Ceramic-Aligning-Ball-Bearings.html

Product description:

Our company produces all kinds of ceramic bearings, including ceramic deep groove ball bearings、ceramic angular contact ball bearings、ceramic aligning ball bearings、ceramic thrust ball bearing. Our production range from diameter 3mm~300mm, precision could reach to P4.

Our products are widely used in petroleum, chemical, electronics, textile, printing , electroplating, instrumentation,medical and other fields. In addition to the high domestic market share, our products are exported to South Korea and Japan. The United States, Britain, France and Germany, Canada, Italy, Australia and more than 10 countries in Southeast Asia.

Depending on the comprehensive power of production, sales, development and technology, we will meet customers’ requirements by quality and reliability. They are the best choices for replacing imported bearings.

Why choose us?

Advantage:

Strong design ability, quick response, consistent quality for each shipment.

Package:

Single plasitc bag+ single box+carton

All package materials been used with high quality, could be storaged for long time and for long-distance sea shipment.

Lead time:

10~30 days depend on material situation and stock

Quality Guarantee:

Strictly control on quality, based on drawings , contracts and approved samples .

When customer feedback quality problems, respond positively and submit 8D report if necessary.
